Rack & Pinion Drive - KRP+ DRP+

Accionamentos piñón cremallera - KRP+ DRP+

FELT PINION & SUPPORT

PIÑÓN DE FIELTRO Y SU SOPORTE

Especially designed for the lubrication of Racks & Pinions Drive systems.

Especialmente diseñado para la lubricación de sistemas piñón cremallera

FGRP1.H.G 3 16 50.9 56.9 30

FGRP2.H.G 4 16 67.9 75.9 40

FGRP3.H.G 5 16 84.9 94.9 50

FGRP4.H.G 6 16 101.9 60

FGRP5.H.G 8 16 135.8 60

ORD. CODE

Module Módulo

Z D 0 D k L 2

113.9 151.8

ORD. CODE

Module Módulo

Z

FGRP1.S.G 3 15 45 51.0 25

FGRP2.S.G 4 15 60 68.0 30

FGRP3.S.G 5 15 75 85.0 40

FGRP4.S.G 6 15 90 50

FGRP5.S.G 8 15 120 60

D 0 D k L 2

102.0 136.0

Adaptator plate for Felt Pinion mounting on DRP+ housing

Felt Pinion - Helical Teeth Felt Pinion - Straight Teeth

D Oil filler input/ Entrada de engrase

M6 x 12

C

2 x CHC : G

B

ØD k

ØD 0

ORD.

CODE A B C E F G

SFRP1 52 100 40 12.5 45 M6x25

SFRP2 65 120 50 15 50 M6x25

SFRP3 76 130 50 17.5 60 M8x25

SFRP4 88 145 65 30 80 M8x25

SFRP5 117 150 80 27.5 80 M10x30

D

helical

Helicoidal

D

straight

Recto

43.5 46.5 56.8 60.8 66.6 71.5 72.6 78.5 63.6 71.5

Size/ Tamaño

DRP+/KRP+

1 2 3 4 5

Felt/Filz

Adaptator plate Pletina soporte

Piñón de fieltro – dentado recto

Pletina de soporte para montaje del piñón de fieltro en la carcasa del DRP+
