Rack & Pinion Drive - KRP+ DRP+

Accionamentos piñón cremallera - KRP+ DRP+

TwinDRIVE

DRP+_-P... +MF

Size 1 Size 2 Size 3 Size 4 Size 5

G H I J K L M n1 n2 n3 n4 O P Q R S T U V W X Y Z

470 190 140 420 140 70 172 6 2 9 6 20 65 103.5 53 17 M12 7.5 227 229 30 20 33.5 24.5 77.5 53 33

560 230 165 500 170 85 210 6 2 9 6 30 75 133 65 22 M16 9.5 300.5 298 35 25 34.5 32.5 100 62 44

650 270 190 570 190 101 245 6 2 9 6 35 80 155 73 26 M20 11.5 357 30 33.5 77.5 55

920 360 280 800 240 157 320 6 2 9 6 50 105 181 102.5 45 M30 13.5 512 45 32.5 120 88

800 320 240 700 220 120 288 6 2 9 6 43 100 166 81 34 M24 11.5 435 35 34.5 100 66

mm

Tamaño 1 Tamaño 2 Tamaño 3 Tamaño 4 Tamaño 5

1S 2S 1S 2S

A - B - C - D - E - F : according to the chosen motor 1 stage / 1 Etapa : 1S - 2 stages / 2 Etapas : 2S

Size 1 : If E > 140 mm, please contact your local supplier

Size 2 : If E > 200 mm, please contact your local supplier

A - B - C - D - E - F : - En función del motor seleccionado

Tamaño 1 : Si E > 140 mm, contactar con su proveedor local

Tamaño 2 : Si E > 200 mm, contactar con su proveedor local
