A. Catep Multispeed Transmissions

This line of multispeed transmissions features

OR SPEEDS IN ONE GEARBOX HOUSING AND from 12 to 288 speeds by coupling up to 4 boxes. Available in 7 sizes over the entire ratio range, with ratings from 5 to 800 hp at 1,500 rpm. Reversing gearboxes are available that can change the direction of rotation either manually or electrically. Applications include wire stranding, wire cabling, take-ups, payoffs, capstans, caterpillar drives, test benches, multi-spindle drill-ing machines and textile processing.

B. BD Series Single-Position Jaw Clutches

These clutches are used wherever different sections of a machine need to be first disengaged from the drive train and then re-engaged while maintaining the same phase or angular

relationship which existed prior to disengagement. They are often used in a line-shaft, between printing units on an offset-printing press, and to disconnect certain units on a finishing line.

C. Reversing Gearboxes

Andantex offers a range of in-line and right angle reversing gearboxes that provide forward, neutral and reverse rotation of the output shaft with respect to the input shaft. Shifting is done by a mechanical slide-dog mechanism so the unit must be at rest to change directions of rotations. Powers range from 3 HP up to 350 HP.

6ALLEY 2OAD 7ANAMASSA .* s s &AX s E-mail info@andantex.com s www.andantex.com

Mechanical Speed Control Units
