www.andantex.com
MOUNTING RECOMMENDATIONS RECOMMANDATIONS DE MONTAGE
CANTILEVER MOUNTING
MONTAGE EN PORTE-A-FAUX
THROUGH SHAFT MOUNTING
MONTAGE SUR ARBRE TRAVERSANT
Location against shoulder and fixed by screw and washer
Fixation et blocage sur épaulement par vis et rondelle
Location against shoulder, and fixed using spacer
Fixation et blocage sur épaulement et entretroise
The accessory fitted to the reaction sleeve must be adjacent to the bearing to avoid excessive bending of the supporting shaft
L’accessoire monté sur la douille doit être obligatoirement situé du côté du palier afin de ne pas imposer à l’arbre une contrainte exagé-rée à la flexion
SR SERIES - Differentials and Reducers SERIE SR - Différentiels et Reducteurs
