www.andantex.com
Rack & Pinion Drive - KRP+ DRP+
Accionamentos piñón cremallera - KRP+ DRP+
DualDRIVE
DRP+_-R... +MF +PLD
Size 1 Size 2 Size 3 Size 4 Size 5
G H I J K L M n1 n2 n3 n4 O P Q R S T U V W X Y Z
470 190 140 420 140 70 172 6 2 9 6 20 65 103.5 53 17 M12 7.5 229 20 24.5 53 33
560 230 165 500 170 85 210 6 2 9 6 30 75 133 65 22 M16 9.5 298 25 32.5 62 44
650 270 190 570 190 101 245 6 2 9 6 35 80 155 73 26 M20 11.5 357 30 33.5 77.5 55
920 360 280 800 240 157 320 6 2 9 6 50 105 181 102.5 45 M30 13.5 512 45 32.5 120 88
800 320 240 700 220 120 288 6 2 9 6 43 100 166 81 34 M24 11.5 435 35 34.5 100 66
mm
A - B - C - D - E - F : according to the chosen motor - En función del motor seleccionado
Tamaño 1 Tamaño 2 Tamaño 3 Tamaño 4 Tamaño 5
