Page 4 - Industrial Gearboxes

The Z-Series product line offers 7 dif-ferent sizes, 6 model types, and 9 ratios, with various input-output arrangements including solid shaft or hollow bore options, as well as uni-versal mounting capability.

All of these options are made possi-ble by a modular design concept that starts with a cubic housing. The Z-Series is an extremely versatile product line, meeting virtually all of the technical office requests.

4

www.andantex.com

OVERVIEW

Z SERIES - Spiral Bevel Gearboxes p 6

The SR Series differential gearbox is based on a compound epicyclic gea-ring system.

A high torque capacity in a very com-pact space is achieved by a paten-ted thermo-plastic injection process which allows an increase in the quan-

tity of planet gears.

The combination of three motion ele-ments and a wide range of reduction ratios provides solutions to many elec-tro-mechanical drive problems.

SR SERIES - Differentials and Reducers p 84

A heavy duty additional range to the Z-Series (360 to 1980 kW). The R-Series product line offers 3 sizes and 3 different ratios, with similar ver-satility to the Z-Series.

R SERIES - Spiral Bevel Gearboxes p 50

The cost-effective C-Series product line offers 2 standard ratios in a simpli-fied design. Its universal mounting cubic frame is made with high stiff-ness aluminium alloy.

C SERIES - Spiral Bevel Gearboxes p 60

A range of multi-speed, reversing and speed multiplier gearboxes, designed for heavy duty and conti-nuous operation.

Standard cast-iron casings offer many different mounting configura-tions.

Customized designs are available for extreme working conditions.

BVI / MVI SERIES - Multispeed p 64

A range of ON / OFF clutches desi-gned for accurate and single cou-pling position.

Available as coaxial shafts or bevel gearbox versions, with or without remote and position control.

BD SERIES - Single-Position Jaw Clutches p 78

The Differential Phase-Shift gearbox is the heart of a registration control sys-tem.

The design allows the angular posi-tion of the output shaft to be accu-raltely adjusted for error correction relative to the input shaft.

In-line and Right-angle versions are available.

With the addition of a motor and an electronic control, a fully automated registration control system can easily be achieved.

D SERIES - Differential Phase-Shifters p 102
